Recently received a consultation from a customer, he needs to use the high viscosity low flow sensor to measure the mixed polymer containing alcohol, chloroform, hydrochloric acid
and other substances. Since the viscosity of the medium will increase at low temperature and even solidify, the customer chooses to use a hot water pad to heat the flow meter,
so that it can ensure the normal circulation of the medium in the flow meter.





he provides the following parameters

A:

Medium: Chloroform-containing polymer solution

Need to be resistant to chloroform and hydrochloric acid

Flow: 2~10ml/min

Polymer viscosity: 700 Poise (70000cp)

Temperature: 57~63℃

Pressure: < 10 bar

Output: 4~20mA

Explosion-proof

the

b.

Medium: bore-liquid (alcohol components such as methanol, ethanol, chloroform, trichloroethylene, etc.)

Need to be resistant to chloroform and hydrochloric acid

Flow: max 10ml/min

Viscosity: 0.5~1.8CP

Temperature: 20 - 60℃

Pressure: < 4 bar

Output: 4~20mA

Explosion-proof

the

c.

Medium: Chloroform-containing polymer solution

Need to be resistant to chloroform and hydrochloric acid

Flow: 200l/h

Viscosity of polymer solution: 70000 ~110000cp

Temperature: 35 ~ 65℃

Pressure: < 5 bar

Output: 4~20mA

Explosion-proof

We suggest that customer use remote display. Flow meter with DC8S remote digital display.

the

The flowmeter is explosion-proof with Hessman joint glue filling.

Flowmeters with filling glue explosion-proof, customer need to prepare an explosion-proof box for digital display, so that the whole explosion-proof.



According to the parameters provided by the customer, we recommend our low flow sensor micro oval gear flow meter G0.015, M5.2SS and G0.4SS to customer.
