acid centrifugal pump
Email:sales01@cxflowmeter.com whatsapp:008618049841995
Today, a customer asked how to choose to buy a hydrochloric acid centrifugal pump. He provided the following specific information:
1.
Medium: hydrochloric acid (concentration up to 2-3%, maximum size 1 mm)
Flow rate: 30m³/h
Differential pressure: 56m
Maximum viscosity: 200cp
Density: 1.1kg/cm³
Working temperature: 20-90℃
Motor: 15 kW B3B5, 160. 2P. V400/690. 50HZ IP55 (reference, similar accepted)
Casing material: polypropylene
Impeller: PP
Shaft: SS316
Mechanical seal
Flange connection: 50/32mm
Bottom plate: SS316
Quantity: 1
2.
Medium: hydrochloric acid (concentration up to 10%, maximum size 9 mm)
Flow rate: 75m³/h
Differential pressure: 38m
Maximum viscosity: 200cp
Density: 1kg/cm³
Operating temperature: 20-90℃
Motor: 11kW 2P. V400/690. 50HZ IP55 (reference, similar accepted)
Casing material: polypropylene
Impeller: PP
Shaft: SS316
Mechanical seal
Threaded connection: 65/50mm
Bottom plate: SS316
Quantity: 3
After analysis, our technicians selected the following specific product models for him:
1.
CQB65-40-250F
Medium: hydrochloric acid (concentration up to 2-3%, maximum size 1 mm)
Flow rate: 30m³/h
Differential pressure: 56m
Maximum viscosity: 200cp
Density: 1.1kg/cm³
Operating temperature: 20-90℃
Motor: 18.5kw -2
Power supply: 400V50HZ
Casing material: steel lined with PTFE
Impeller: PTFE
Shaft: Silicon nitride
Mechanical seal
O-ring material: fluororubber
Flange connection: 65/40
Bottom: SS316
2.
CQB100-65-200F
Medium: hydrochloric acid (concentration up to 10%, maximum size 9 mm)
Flow rate: 75m³/h
Differential pressure: 38m
Maximum viscosity: 200cp
Density: 1kg/cm³
Working temperature: 20-90℃
Motor power: 30kw-2
Power supply: 400V50HZ
Casing material: steel lined with PTFE
Impeller: PTFE
Shaft: Silicon nitride
Mechanical seal
O-ring material: fluororubber
Flange connection: 100/65
Bottom: SS316
